1PCS CH376S USB Module Read/Write Modular Device Main-interface Unit

TEJIATE/特加特
In stock
¥4.39
Color

Secure checkout

Friendly support

Hassle-free returns

Product Brief

CH375 is a universal interface chip of USB bus, which supports USB-Host mode and usb-device / slave device mode. At the local end, CH375 has 8-bit data bus, read-write, chip select control line and interrupt output, which can be easily connected to the system bus of MCU / DSP / MCU / MPU and other controllers. In the USB host mode, CH375 also provides a serial communication mode, which is connected with MCU / DSP / MCU / MPU through serial input, serial output and interrupt output. The USB device mode of CH375 is fully compatible with h372 chip, and CH375 includes all functions of CH372. The USB host mode of CH375 supports the commonly used USB full speed device, and the external MCU can communicate with the USB device through CH375 according to the corresponding USB protocol. CH375 also has the firmware of special communication protocol for mass storage device. The external MCU can read and write the USB storage device (including USB hard disk / USB flash disk / USB flash disk) in the basic unit of sector.
CH376S USB Module Read/Write Modular Device Main-interface Unit

Product function

1. CH376 is a universal interface chip of USB bus. It has 8-bit data bus, read-write, chip selection control line and interrupt output. It can be easily connected to the system bus of MCU / DSP / MCU / MPU and other controllers. In the USB host mode, CH376 also provides a serial communication mode, which is connected with single chip microcomputer / DSP / MCU / MPU, etc. through serial input, serial output and interrupt output.
2. 2x8 connector, easy to connect with MCU
3. According to jumper selection, it can work in parallel mode or serial mode
4. USB status indicator
5. On board 3.3V LD0 1117, maximum 800mA current
6. 5V power is supplied by the target board
7. 12Mhz vibration

Product characteristics

Low speed and full speed usb-h0st host interface, compatible with usbv2.0, only crystal and capacitor are needed for peripheral components.
Low speed and full speed USB device interface, fully compatible with chip CH372, supports dynamic switching between host and device mode.
The input and output buffers of the host endpoint are 64 bytes each, supporting 12mbps full speed device and 1.5mbps low-speed device.
Support USB device control transmission, batch transmission, interrupt transmission.
Automatically detect the connection and disconnection of USB device, and provide device connection and disconnection event notification.
The built-in firmware deals with the special communication protocol of mass storage devices, supports bulk-0nly transfer protocol and USB storage devices of SCSI, UFI, RBC or equivalent command set (including USB hard disk / USB flash disk / USB disk / USB card reader)
The file level subroutine library of USB disk is used to read and write files in USB storage device.
Parallel interface includes 8-bit data bus, 4-wire control: read gate, write gate, chip select input, interrupt output.
Serial interface includes serial input, serial output and interrupt output, and supports dynamic adjustment of communication baud rate.
Support 5 power supply voltage and 3.3V power supply voltage, support low power consumption mode.
It adopts s0p-28 lead-free package, compatible with ROHS, provides conversion board from s0p28 to dip28, and the pin is basically compatible with chip ch374.
